12-11
3.
Carefully and firmly pull the enclosure straight back off the
valve
4. Cut the rubber bulb and attach the TTV tool to the valve.
Remove the valve from the rim by pulling through the rim, or
simply pull through without cutting the bulb
5. Lift the outer tyre bead over the rim using a tyre tool
The valve must be positioned just left of the start position
to avoid sensor damage. Do not touch the sensor with the
tyre tool.
6. Lift the inner tyre bead over the rim using the tyre tool
7. Remove existing valve stem
Starting to mount the tyre from the valve location is a wrong
fitment. Fixing tool/stem may hit the sensor and damage it.
Start from the opposite direction.
WHEELS AND TYRES
