5.3. SERVICE AREAS
5.3.1.
RH SIDE SERVICE NOTE:
If a lift cylinder hose
is replaced, always locate and secure hose as shown
in photo to prevent hose from being pinched between
loader and cylinder causing damage to hose.
RH Lift Cylinder Base End Hose
RH Lift Cylinder Rod End Hose
Nylon Ties
NOTE: Route hoses so they either do not contact
notch area or they only rest against notch area.
Do not twist hoses so they are pulled against
notch area.
5.3.2.
LH SIDE SERVICE NOTE:
If a lift cylinder hose
is replaced, always locate and secure hose as shown
in photo to prevent hose from being pinched between
loader and cylinder causing damage to hose.
LH Lift Cylinder Rod End Hose
LH Lift Cylinder Base End Hose
Nylon Ties
