ABSOLUTE mm
0.001
-0.01 0 0.01
Ó ut tu
Measurement Display Setup System
Absolute mode
Customer calibration
Factory calibration
Factory settings
Keyboard-/ menu interlock
Info
t q
ü
Measurement Display Setup System
Absolute mode
Customer calibration
Factory calibration
Factory settings
Keyboard-/ menu interlock
Info
Ó
ü
q p
ü
6. System menu
6.1 Selecting absolute mode
– Press the ON / OFF key
=> Standard menu appears
– Press u to select the System
menu
– Press q to select the Absolute
mode submenu
– Press
ü to conrm
– Mechanically set probe to “0”.
– Press the u t and t u keys to
adjust the scale
– Press ü to conrm
– Press the ON / OFF key to exit the
input menu.
To guarantee the maximum possible accuracy, the measuring probe should be
mechanically set to the electrical zero point before the rst measurement is
conducted. Setting mode that indicates the raw value or absolute value of the
probe should be used for this purpose.
!
