8. Technical data
8.1 Compact length measuring instrument Millimar C 1200
Order no. Mahr: 5312010
Product type: Millimar C 1200
Display: TFT color display, 4.3 inch, 480 (W) x 272(H) pixels
Keypad: Membrane keypad, 1 million actuations
Units: µm, mm, inch
Range of digital display: ±1000 mm
Range of analog display:
Resolution:
µm: 10; 1; 0.1
mm: 0.01; 0.001; 0.0001
inch: 0.0001; 0.00001; 0.000005
Tolerance display: Background color: green/red
Measuring ranges, inductive probe: ± 1 mm, ± 2 mm, ± 5 mm
Probe inputs: 1
Compatibility: Mahr
Data transmission rate: 30 values per second
Measuring combinations: +A / -A
Measuring functions: Normal, Max, Min, Max-Min
Features: 1
Refresh rate: 40 fps (frames per second)
Error limit, digital display: 0.2 µm or 0.3% of the displayed probe value *
* The larger value applies
Error limit, analog display: 0.25% of the end scale value / 0.3% of the displayed value*
* The larger value applies
Data interface: Digimatic, Opto RS232C, USB, optional wireless transmission
Power supply: Mains powered 100 -230 Volt / 7.5 V, 1.7 A (4102060)
or battery / rechargeable battery
Battery / rechargeable battery type: AA cells, 1.2 to 1.5 Volt
Operating time with battery /
rechargeable battery: > 8 h *
* Dependent upon the capacity of the batteries / rechargeable batteries used, the brightness
of the screen and the ECO Mode settings
IP protection class: 42
Weight without / with batteries: 496/620 g
Working temperature range: 10 °C – 35 °C
Operating temperature range: 0 °C – 40 °C
Storage temperature range: -10 °C – 60 °C
Dimensions W/H/D: Angle of the display - 0 degrees: 128.8/58.9/151 mm
Angle of the display - 90 degrees: 128.8/166.9/150 mm
Distance between mounting holes: 65.5 mm
Measuring range / µm ±5000 ±2000 ±1000 ±300 ±100 ±30 ±10 ±3
Measuring range / mm ±5 ±2 ±1 ±0.3 ±0.1 ±0.03 ±0.01 ±0.003
Measuring range / inch ±0.19 ±0.07 ±0.03 ±0.01 ±0.003 ±0.001 ±0.0003 ±0.0001
Dial graduation / µm 500 200 100 20 10 2 1 0.2
