Calibration Min Nominal value Calibration Max
-1.000 -0 1.000
Measurement Display Setup System
Customer calibration
+
0 0 1 . 0 0
0
3 Ó
ü
q p
Calibration Min Nominal value Calibration Max
-1.000 -0 1.000
Measurement Display Setup System
Customer calibration
Calibration Min
and accept
3 Ó
ü
q p
Calibration Min Nominal value Calibration Max
-1.000 -0 1.000
Measurement
Display Setup System
Customer calibration
Calibration Max
and accept
Measurement Display Setup System
Absolute mode
Customer calibration
Factory calibration
Factory settings
Keyboard-/ menu interlock
Info
Ó
ü
q p
ü
– Enter value for Calibration Max
(e.g. +1.000 mm). Press u to
select the required position and
press q p to enter the required
value.
– Press ü to conrm or Ó to cancel
the selection
– Move the Probe to the Min
position (e.g. measuring plate)
=> The following appears on the
display:
Set probe to Calibration Min and
accept
– Press ü to conrm
– Move the probe to the Max
position (e.g. 2.000 mm gauge
block)
=> The following appears on the
display:
Set probe to Calibration Max and
accept
– Press ü to conrm
=> Probe calibration according to
the customer's specication is
complete and activated.
– Press the ON / OFF key to exit the
input menu.
