MP2600D, MP2600C & MP1700E Series Installation Manual V1.4
Maipu Confidential & Proprietary Information Page 18 of 52
The MP2600D, MP2600C & MP1700E main board includes 12/4/4 fixed
interface, one voice card slot, one MIM slot, eight indicators and power
supply slots.
Fixed interface
The MP2600D, MP2600C and MP1700E provide fixed console port, Ethernet
interface, high-speed sync/async interface and asynchronous serial, which
is totally 12/4/4 fixed interfaces.
Console port
Console port attributes:
Attributes Description
Converter type RJ45
Interface standard RS232
BR 9600bps - 115200bps
Supported service Connect to character terminal
Connect to local PC serial, and operate
terminal emulation program command line
interface on PC
Ethernet interface
Ethernet interface attributes:
Attributes Description
Converter type RJ45
Interface number 2
Supported frame format Ethernet_II
Ethernet_SNAP
IEEE 802.2
IEEE 802.3
Working mode 10M/100M adaptive
Full/half-duplex
Auto across
Supported network protocol IP
Novell IPX
