Indicator description:
2-port switch VoIP module (2VOS) indicator:
V1 VoIP module indicator.
LED on: during the phone call
V2 VoIP module indicator.
LED on: during the phone call
2VOS Module Connected Cable
2VOS module connected cable is RJ45 external cable.
2VOS Module Interface Attributes
2-port switch VoIP module (2VOS) interface attributes:
Attributes Description
Interface RJ45 jack
Interface number 2 (RJ11)
Supported protocol H.225
H.245
RTP
RTCP
G.711
G.723
G.729
Ethernet Module (ETE) Series
1-port Ethernet Module (1ETE)
1-port Ethernet module realizes Ethernet connection.
1ETE Module & Indicator
1ETE module:
