Maipu MP2600C Series User Manual

MP2600D, MP2600C & MP1700E Series Installation Manual V1.4
Maipu Confidential & Proprietary Information Page 30 of 52
Indicator description:
1-port ISDN U module (1U) indicator:
ACT
The LED on after link established
B1
B1 channel indicator
LED on: when using channel B1, and rate is 64K
B2
B2 channel indicator
LED on: when using channel B2, and the rate is 128K
1-port ISDN U module (1U) DIP switch:
Mode DIP switch Description
1 2
Loopback ON Reserved
1U Module Connected Cable
1U module connected cable RJ45 (4, 5 signal line) or RJ11 telephone line.
1U Interface Attributes
1U interface attributes:
1-port ISDN U module (1U) interface attributes:
Attributes Description
Tie-in RJ45
Interface number 1
Supported link
protocol
PPP
Supported network
protocol
IP
IP Module (VOP/VOS) Series
1-port VoIP Module (1VOP)
1-port VoIP module accesses any telephone through IP network; You can
easily realize free phone call through IP network.
1VOP Module Indicator
1VOP interface module:
