MP2600D, MP2600C & MP1700E Series Installation Manual V1.4
Maipu Confidential & Proprietary Information Page 31 of 52
1-port VoIP module (1VOP)
1-port VoIP module (1VOP) indicator:
V1 VoIP module indicator. The LED is on during the call.
V2 1VOP module may not have this LED, and if it has, the LED will
be not on.
1VOP Module Connected Cable
1VOP module connected cable is RJ45 (4, 5 signal line) and RJ11 telephone line.
