MP2600D, MP2600C & MP1700E Series Installation Manual V1.4
Maipu Confidential & Proprietary Information Page 43 of 52
Module Installation
The routers adapt modular system structure and different kinds of
interface configuration.
Module installation steps:
Step 1: Choose the module and interface.
Step 2: Inset the module to slot. Insert the module circuit board into
interface card slot.
Step 3: Push in the module close to back panel.
Step 4: Tighten the screw.
Rack/Desk
Installing routers to 19-inch standard rack:
Front-end installation method:
Step 1: Install ear bracket to both sides of front-end of
MP2600D/MP2600C/MP1700E and fix with screw.
Step 2: Place router on standard rack and connect bracket and metal
frame with screw.
Panel Wire Connection
Panel wire connection includes Ethernet interface cable, WAN sync/async
cable connection.
To Next Page
