MP2600D, MP2600C & MP1700E Series Installation Manual V1.4
Maipu Confidential & Proprietary Information Page 40 of 52
Chassis Installation
Tools & Equipment
Tools:
Screwdriver
Anti-static equipment
Connected cables:
Console port cable
Ethernet cable （ MP2600D/MP2600C/MP1700E Ethernet cable is
configured according to the number of Ethernet modules）
Modular interface cable
Equipment:
Ethernet 10 BASE-T HUB
Configuring terminal (can be PC)
Equipment relevant to optional module
