Page #50 background imageLoading...
Page #50 background image
MP2600D, MP2600C & MP1700E Series Installation Manual V1.4
Maipu Confidential & Proprietary Information Page 50 of 52
Interface Cable Signal
Ethernet Interface Cable
MP2600D/MP2600C/MP1700E router Ethernet interface cable is 8-pin
unshielded twisted-pair. Pin 1,2 is transmit and pin 3,6 is receive. They
can be connected with HUB.
RJ45 Signal Direction RJ45 Length
1 TX+ —> 1 2m
2 TX- —> 2
3 RX+ <— 3
6 RX- <— 6
4 --- --- 4
5 --- --- 5
7 --- --- 7
8 --- --- 8
RJ45 cross cable (type-5 twisted-pair) pin configuration
RJ45 Signal Direction RJ45 Length
1 TX+ —> 3 2m
2 TX- —> 6
3 RX+ <— 1
6 RX- <— 2
4 --- --- 7
5 --- --- 8
7 --- --- 4
8 --- --- 5
