Major tech MT390 - Using the RCD Function (cont. 2); RCD Function Menu Navigation

5.2.6-RCD Function Menu Operation
Main Display
RCD AUTO Other
Menu Display
Pop-up and shutdown RCD menu , Shutdown mode is activated when the user selects.
Pop-up and shutdown Trip Current menu , Shutdown mode is activated when the user selects
Pop-up and shutdown Type of RCD menu , Shutdown mode is activated when the user selects
Pop-up and shutdown Type of 0°/180° menu , Shutdown mode is activated when the user selects
Up menu to select the current active sub-options.
Down menu to select the current active sub-options.
Confirm the user select mode.
F1 Button:
F2 Button:
F3 Button:
F4 Button:
Up Button:
Down Button:
Enter Button:
24
00:45
Multifunction Tester User Manual
