mammotome REVOLVE - Page 20

2-10
Figure 10. EX Probe, Vacuum Tube Set, and Sleeve Illustrations and Nomenclature
Table 3. Mammotome revolve EX Probe Specifications
Dimension (mm)
8G
MHEX08 AND MHEX08S
A: Needle Height
5.99 mm (6.0)
B: Needle Width
4.26 mm (4.3)
C: Tip to Center
23.3 mm
D. Needle Length
92 mm
E: Dead Space
10.8 mm
F: Aperture Length
25.0 mm
Fill Volume (cc)
9
