• This screen is displayed once the system is fully
initialized and ready to perform clinical functions.
• In this screen, the user can adjust the following
procedure settings:
o Set Aperture
o Adjust Biopsy Mode
o Set Specimen View Position
o Advance to Chamber 7/Reset
Chambers
o Set Vacuum Level
o Turn SteadyVac ON/OFF
o Volume
o Screen Brightness
• During tissue sampling or other clinical functions,
the graphics on the screen reflect the function
being performed by the system. The touch buttons
are lit when the setting they control is available to
be adjusted. When the function is not available
(i.e. during tissue sampling) the corresponding
button is dim.
