3-4
c. Flip the On/Off switch at the back of the control module to the ON (I) position. Once the switch is in
the ON position, the power button in the front illuminates amber, indicating the machine is receiving
power but the control module is not active.
d. Press the amber power button on the front of the control module until it illuminates GREEN. The title
screen appears on the display and the system proceeds to the first software screen prompt.
WARNING: DO NOT touch exposed cord connectors or cord connector ports when the control
module power is on (I).
WARNING: Do not touch exposed parts of connectors on the control module, holster, or touchscreen
while simultaneously contacting the patient, as safety hazards may exist.
WARNING: To ensure adequate ventilation, position the control module at least 6" (15.24 cm) from all
walls. Do not block the exhaust fan at the rear of the control module. Do not position the
device where it is difficult to operate the mains disconnect device. The power switch is
used for mains disconnect.
NOTE: Never use a sharp object to activate the touchscreen.
e. If a holster has already been attached, the control module recognizes the device and displays a
screen prompt to attach a probe. (See Step 6: Loading the Mammotome revolve Probe onto the
Mammotome revolve Holster.) If no holster has been attached, the touchscreen interface on the
control module displays prompt:
A holster must be attached via the holster connection port to proceed with setup.
2. Connecting the Holster to the Control Module
NOTE: Do not connect the holster to the control Module when the power is On.
a. Align the red indicator mark on the holster electrical cable connector with the connection port on the
front of the control module.
b. Push the electrical cable connector into the connection port until an audible click is heard. Proper
connection of the holster to the control module advances the software to the next screen prompt,
“Attach Probe”.
NOTE: Do not force the holster cable connector into its receptacle (Control Module connection port).
If the holster cable connector is difficult to attach, ensure proper alignment to the receptacle
before re-attempting to insert.
