ADD-ONUNITS

Specialtools

[6]

Specialspanner

•Removing,installingthepoly-V-beltpulleyin

conjunctionwith:

•Gripper[7]

80.99603-6029

[7]

Gripper

•Removing,installingthepoly-V-beltpulley

08.06460-0002

[8]

Cabletiepliers

•Tighteningandcuttingoffthecableties

08.02960-0100

100AE63stedition
