COMMONRAILSYSTEM
Attachingthefuellinehigh-pressurepumptop
–handpump
•Removetheendplugsandprotectivesleeves
•Positionthefuelline(2)
•Screwonandtightenunionnuts(1)and(3)
Attachingthefuellinehigh-pressurepumptop
–fuellter
•Removetheendplugsandprotectivesleeves
•Positionthefuelline(2)
•Screwonandtightenunionnuts(1)and(3)
Attachingthefuellinedrain–lter
•Removetheendplugsandprotectivesleeves
•Positionthefuelline(3)
•Screwonandtightenunionnuts(1)and(2)
Attachingthefuelreturnline
•Removetheendplugsandprotectivesleeves
•Positionthefuelline(2)
•Screwonandtightenunionnuts(1)and(3)
Attachingthefuellinehandpump–
high-pressurepump
•Removetheendplugsandprotectivesleeves
•Positionthefuelline(2)
•Screwonandtightenunionnuts(3)and(4)
•Screwinandtightenthemountingbolt(1)
