VALVETIMING
Installingthecamshaft
InstallingtherollertappetInstallingtheroller
tappet
•Thinlyapplycleanengineoilontherollertappet
(1)
•Aligntherollertappet(1)withtherecess(2)facing
thetappedholefortheanti-rotationdevice(3)
•Inserttherollertappet(1)intothecrankcase(4)
Screwingintheanti-rotationdevice
WARNING
Dangerofdamagetotherollertappets
oranti-rotationdevices
•Ensurethattheanti-rotationdevice
engagesintherollertappetrecess
•Screwinthenewanti-rotationdevices(1)and(2)
•Tightentheanti-rotationdevices(1)and(2)to22
Nm
Installingthecamshaft
•ThinlyapplycleanengineoiltoMANStandard
3277onthecamshaftbearing
•ScrewtheInsertionpin[99]intothecamshaft(1)
•Pushinthecamshaft(1)carefullyfromthe
ywheelsidewiththeInsertionpin[99]
Detachingtheinsertionpin
•UnscrewtheInsertionpin[99](1)fromthe
camshaft
Mountingtheaxialshim
•Positiontheaxialshim(1)
•Screwinandtightenthemountingbolts(2)
248AE63stedition
