ENGINELUBRICATION
Rightoilmoduleremovalinstructions
•Donotunscrewtheoilcoolermountingbolts(1)
toremovetheoilmodule
Detachingtherightoilmodule
•Marktheinstallationpositionofthemountingbolts
(3),(4),(5)and(6)
•Unscrewthemountingbolts(3),(4),(5)and(6)
•Removetheoilmodule(2)withseal(1)
•RemovetheO-rings(7)
•Cleanthesealingsurfaces
Installingtheoilmodule
Installingtherightoilmodule
•Cleanthesealingsurfaces
•InsertnewO-rings(7)
•Positiontheoilmodule(2)withanewseal(1)
•Screwinthemountingbolts(3)and(5)asmarked
•Screwinthemountingbolts(4)and(6)asmarked
Tighteningdiagramforrightoilmodule
•Tightenthemountingbolts(4)
•Unscrewthemountingbolts(4)60°
•Tightenthemountingbolts(1),(2),(3)and(5)
•Tightenthemountingbolts(4)
272AE63stedition
