ENGINELUBRICATION
Axialplay,rotor.............................................................................................................0.035–0.080mm
Mountingbolt,oilpump.........................................M6x40-10.9.......................................................15Nm
Importantinformation
WARNING
Componentdamageduetoincorrectlytightenedscrew/boltconnections
•Ifimpactwrenchesareused,thesemayonlybeusedforpretighteningtomax.50%ofthe
speciedtighteningtorque
•Finaltighteningmustalwaysbeperformedmanuallyusingatorquewrench
Specialtools
[107]
Dialgaugeholder
•Checkingtheringgearaxialandradialplayin
conjunctionwith:
•Dialgauge[108]
80.99605-0172
[108] Dialgauge
•Checkingtheringgearaxialandradialplayin
conjunctionwith:
•Dialgaugeholder[107]
08.71000-3217
290AE63stedition
