ENGINEELECTRICS
Removingtheenginecontrolunits
Disconnectingtheenginecontrolunit(slave)
electricalconnections
•Marktheinstallationpositionofthewiring
harnessesandcableties
•Fullyunlockandpullofftheconnectors(1),(2)and
(3)
•Marktheinstallationpositionofthecabletiesand
thendisconnect
•Exposethewiringharnesses
Disconnectingtheenginecontrolunit(master)
electricalconnections
•Marktheinstallationpositionofthewiring
harnessesandcableties
•Fullyunlockandpullofftheconnectors(1),(2)and
(3)
•Marktheinstallationpositionofthecabletiesand
thendisconnect
•Exposethewiringharnesses
Detachingtheenginecontrolunit(slave)
•Unscrewthemountingbolts(3)andremovewith
thebracket(1)
•Removetheenginecontrolunit(2)fromthe
bracket
Detachingtheenginecontrolunit(master)
•Unscrewthemountingbolts(1)
•Removetheenginecontrolunit(2)fromthe
bracket(3)
Detachingtheenginecontrolunitbracket
•Unscrewthemountingnuts(4)andremovewith
washers(3)
•Pulloutthemountingbolts(1)
•Removethestopforcontrolunitbracket(2)
AE63stedition29
