CRANKMECHANISM
Glycomainbearingdimensions
Wallthickness,mainbearing,normaldimension.............................................................2.959–2.971mm
Wallthickness,mainbearing,normaldimensionII..........................................................3.084–3.096mm
Wallthickness,mainbearing,repairlevelI.....................................................................3.209–3.221mm
Wallthickness,mainbearing,repairlevelII....................................................................3.334–3.346mm
Expansion....................................................................................................................................2.0mm
Glycothrustwasherdimensions
Thrustwasherthickness,normaldimension...................................................................3.350–3.400mm
Serviceproducts
Loctite5900......................................................................................................................04.10394-9272
Importantinformation
WARNING
Componentdamageduetoincorrectlytightenedscrew/boltconnections
•Ifimpactwrenchesareused,thesemayonlybeusedforpretighteningtomax.50%ofthe
speciedtighteningtorque
•Finaltighteningmustalwaysbeperformedmanuallyusingatorquewrench
Specialtools
[146]
Dialgauge
•Checkingthecrankshaftaxialandradialplayin
conjunctionwith:
•Dialgaugeholder[147]
•Locatingpin[148]
08.71000-3217
[147] Dialgaugeholder
•Checkingthecrankshaftaxialandradialplayin
conjunctionwith:
•Dialgauge[146]
•Locatingpin[148]
08.71082-0005
[148] Locatingpin
•Checkingthecrankshaftaxialandradialplayin
conjunctionwith:
•Dialgaugeholder[147]
•Dialgauge[146]
80.99605-0197
[149]
Settingtool
•Positioningthebearingshell,crackedconnecting
rod
80.99622-0052
[150] Aligningtool
•Removing,installingthecrankshaftinconjunction
with:
•Aligningtool[151]
80.99617-0020
AE63stedition335
