CRANKMECHANISM

Screwinginthealigningtools

•ScrewintheAligningtool[150](1)atthefrontof

thecrankshaft

•ScrewintheAligningtool[151](2)attherearof

thecrankshaft

Liftingoutthecrankshaft

CAUTION

Dangerofinjuryduetoincorrectlifting

gear

•Useseparateliftinggearwithequal

lengthforeachaligningtool

WARNING

Componentdamageduetoincorrect

liftinggear

•Donotuseanyliftinggearorsteel

cableswithsharpedgestoliftoutthe

crankshaft

•Attachtheliftinggearusingthealigningtools

•Liftoutthecrankshaft(1)

•UnscrewtheAligningtool[150]atthefront

•UnscrewtheAligningtool[151]attherear

Removingthecrankshaftbearingshellsfromthe

crankcase

•Markthecrankshaftbearingshells(1)toindicate

correctassignmentandinstallationposition

•Removethecrankshaftbaringshells(1)

•Marktheinstallationpositionofthethrust

washers(2)

•Removethethrustwashers(2)

Pullingoffthecrankshaftgear

•Pullthecrankshaftgear(2)offthecrankshaft(3)

withThree-armpuller[154](1)
