CRANKMECHANISM

Detachingthecrankcaselowersection

CAUTION

Dangerofinjuryduetoheavy

components

•Liftoffthecrankcaselowersectionwith

support

WARNING

Componentdamageduetomain

bearingshellsfallingout

•Makesurethemainbearingshellsdo

notfalloutwhenliftingoffthecrankcase

lowersection

•ScrewthePullerscrew[152]intothecrankcase

lowersectionatthepositions(1)V8engineand

(2)V12engine

•TightenthePullerscrew[152]byhand

•ScrewinthePullerscrew[152]alternately,one

turnatatime

•Afterthisisdonethreetimes,thePuller

screw[152]boltheadcomesintocontact

DonottightenthePullerscrew[152]

•Liftoffthecrankcaselowersectioninconjunction

withtheEye-bolt[153](3)and(4)

•Cleanthesealingsurfaces

Removingthemainbearingshellsfromthe

crankcaselowersection

•Marktheinstallationpositionofthecrankshaft

bearingshells(1)

•Removethecrankshaftbaringshells(1)

•Checknoneofthettedsleeves(2)aremissing;

V12enginehas14items

Removingthethrustwashersatthebottom

•Marktheinstallationpositionofthethrust

washers(1)

•Removethethrustwashers(1)

AE63stedition343
