CRANKMECHANISM
Insertingthecrankshaft
CAUTION
Dangerofinjuryduetoincorrectlifting
gear
•Useseparateliftinggearwithequal
lengthforeachaligningtool
WARNING
Componentdamageduetoincorrect
liftinggear
•Donotuseanyliftinggearorsteel
cableswithsharpedgestoliftoutthe
crankshaft
WARNING
Componentdamagewheninserting
thecrankshaft
•Makesurethatthecrankshaftdoesnot
collidewithothercomponentswhen
beinginstalled
•ScrewintheAligningtool[150]atthefrontofthe
crankshaft(1)
•ScrewintheAligningtool[151]attherearofthe
crankshaft(1)
•Attachtheliftinggearusingthealigningtools
•ThinlyapplycleanengineoiltoMANStandard
3277onthemainbearingjournalofthecrankshaft
(1)
•Insertthecrankshaft(1)intothecrankcase
Unscrewingthealigningtools
•UnscrewtheAligningtool[150](1)atthefrontof
thecrankshaft
•UnscrewtheAligningtool[151](2)attherearof
thecrankshaft
Installingthethrustwashersatthebottom
•ThinlyapplycleanengineoiltoMANStandard
3277onthecleanedthrustwashers(1)
•Putthethrustwashers(1)ontothenalbearing
seatasmarked,withtheoilgroovesfacingthe
crankshaft
AE63stedition347
