–93–
EC20 (WITH TIMER) SELF-CONTAINED AIR-COOLED — STANDARD CUBE
NOTE: These characteristics may vary depending on operating conditions.
Cycle Times
Freeze Time + Harvest Time = Total Cycle Time
Continued on next page …
Air Temp.
Entering
Condenser
°C
Freeze Time
Harvest
Time
Times in minutes.
Water Temperature °C
10 15 20 25 30 35 40
10 18.6-21.2
3.5 min.
15 20.3-23.1 21.3-24.1
20 22.3-25.3 24.6-27.9 26.0-29.4 27.5-31.1 30.9-34.9
25 26.0-29.4 27.5-31.1 29.1-32.9 32.9-37.2 35.2-39.7
30 29.1-32.9 30.9-34.9 35.2-39.7 37.8-42.6 40.7-45.9 48.1-54.1 52.8-59.3
35 40.7-45.9 44.1-49.7 52.8-59.3 58-.4-65.6 65.3-75.3
40 65.3-73.3 73.9-82.9 99.7-111.7
45 85.0-95.2 120.3-134.7 151.3-169.3
