Part Number 80-1479-3 10/10 47
HOT GAS VALVE WON’T ENERGIZE
SCR Timer
1. Line voltage at hot gas valve? (Wires 6& 7)
Yes - Replace hot gas valve coil.
No - Refer to SCR timer diagnostics.
(22)
NCC
NO
6
2
TIME DELAY
RELAY
1
RELAY
HOT GAS
SOLENOID
WATER INLET
SOLENOID
(21)
(9)
(7)
(10)
(6)
1
