64 Part Number 80-1479-3 10/10
BIN THERMOSTAT
Function
The bin thermostat stops the ice machine when the bin
is full. When ice cubes contact the bin thermostat bulb
holder, the bin thermostat opens and stops the ice
machine. When ice cubes no longer contact the bin
thermostat bulb holder, the bin thermostat closes and
the ice machine starts.
Specifications
Check Procedure
Make sure bulb is inserted correctly 35.5 cm in the
bulb well. Disconnect the wires from the bin thermostat
and check the resistance across the terminals.
NOTE: After covering/uncovering the bulb holder with
ice, wait at least three minutes to allow the thermostat
to react. (Open/Close)
Control Setting
Bin Thermostat
Cut in: 4.5°C
Cut out: 1.0°C
Disconnect electrical power to the entire ice
machine before proceeding.
No Ice on Bulb Ice on Bulb Result
Closed (O) Open (OL) Thermostat good
Open (OL) Closed (O)
Replace
thermostat
