–95–
EC20 (WITH TIMER) SELF-CONTAINED AIR-COOLED — STANDARD CUBE (Continued)
Operating Pressures
Air Temp. Entering
Condenser °C
Freeze Cycle Harvest Cycle
Discharge Pressure Suction Pressure Discharge Pressure Suction Pressure
All pressures are in bar. Suction pressure drops gradually throughout the freeze cycle.
10 7.24-4.83 1.38-0 2.76-3.45 1.72-2.76
20 11.38-6.89 1.72-0.34 3.45-5.51 2.76-4.14
43 20.68-13.79 2.76-0.69 4.14-9.30 4.14-6.89
