–106–
EC30 SELF-CONTAINED AIR-COOLED — LARGE CUBE (Continued)
24 Hour Ice Production
Air Temp. Entering
Condenser °C
Water Temperature °C
10 15 20 25 30 35 40
10 36
15 33 32
20 29 28 27 27 26
25 25 24 24 23 22
30 21 21 20 19 18 18 17
35 16 15 15 14 13
40 11 10 9
45 7 6 6
Based on average ice weight of 0.74 - 0.79 kg per cycle. Individual cube weight 32 grams ±1.
Number of individual cubes per cycle: 24
