–113–
EC30 (SERIAL BREAK NOT AVAILABLE) SELF-CONTAINED AIR-COOLED — LARGE CUBE (Continued)
Operating Pressures
Air Temp. Entering
Condenser °C
Freeze Cycle Harvest Cycle
Discharge Pressure Suction Pressure Discharge Pressure Suction Pressure
All pressures are in bar. Suction pressure drops gradually throughout the freeze cycle.
10 8.96-6.89 1.72-0 2.76-5.51 1.72-4.14
20 11.03-7.93 2.07-0 2.76-6.89 2.76-5.51
43 8.27-12.41 2.07-0.69 3.10-7.58 3.10-7.58
