–122–
EC40 SELF-CONTAINED WATER-COOLED — STANDARD CUBE (Continued)
Operating Pressures
Condenser Water
Consumption
32 Air Temperature Around Ice Machine
Water Temperature °C
15 21 32
Gal/24 Hours 478 744 2283
Water regulating valve set to maintain 9 bar discharge pressure.
Water Temperature
Entering Condenser °C
Freeze Cycle Harvest Cycle
Discharge Pressure Suction Pressure Discharge Pressure Suction Pressure
Set water regulating valve to 9 bar 5 minutes into freeze cycle.
All pressures are in bar.
Suction pressure drops gradually throughout the freeze cycle.
10 10.34-8.62 1.79-.28 3.10-5.87 2.07-3.45
20 11.03-8.62 1.79-.34 3.10-7.24 2.07-4.82
25 11.03-8.62 1.79-.41 3.10-7.24 2.07-4.82
32 11.03-8.62 2.00-.41 3.10-7.24 2.07-4.82
43 11.72-8.62 2.00-.48 3.45-8.62 2.07-5.87
