–143–
EC65 SELF-CONTAINED AIR-COOLED — LARGE CUBE (Continued)
Operating Pressures
Air Temp. Entering
Condenser °C
Freeze Cycle Harvest Cycle
Discharge Pressure Suction Pressure Discharge Pressure Suction Pressure
All pressures are in bar. Suction pressure drops gradually throughout the freeze cycle.
10 12.07-9.65 4.14-1.72 6.21-7.58 4.83-6.21
20 15.86-12.41 4.14-1.93 8.27-11.03 5.52-7.93
25 17.58-15.17 4.48-2.07 8.27-11.72 7.58-9.31
32 20.68-17.24 4.83-2.21 8.27-13.79 8.62-10.69
43 25.51-22.06 5.52-2.41 9.31-14.82 9.65-12.07
