–158–
EC80 SELF-CONTAINED WATER-COOLED — STANDARD CUBE (Continued)
Operating Pressures
Condenser Water
Consumption
32 Air Temperature Around Ice Machine
Water Temperature °C
15 21 32
Gal/24 Hours 781 1480 8893
Water regulating valve set to maintain 15.9 bar discharge pressure.
Water Temperature
Entering Condenser °C
Freeze Cycle Harvest Cycle
Discharge Pressure Suction Pressure Discharge Pressure Suction Pressure
Set water regulating valve to 9 bar 5 minutes into freeze cycle. All pressures are in bar. Suction pres-
sure drops gradually throughout the freeze cycle.
10 15.86-15.51 4.14-2.00 8.27-10.68 5.52-6.89
20 15.86-15.51 4.14-2.00 8.96-12.41 6.21-8.27
25 15.86-15.51 4.14-2.00 8.96-12.41 6.21-8.27
32 15.86-15.51 4.48-2.07 8.96-12.41 6.55-8.27
43 17.24-16.20 4.48-2.07 8.96-12.41 6.89-8.96
