EC80 SELF-CONTAINED WATER-COOLED — LARGE CUBE (Continued)
Operating Pressures
Condenser Water
Consumption
32 Air Temperature Around Ice Machine
Water Temperature °C
15 21 32
Gal/24 Hours 826 1316 9060
Water regulating valve set to maintain 15.9 bar discharge pressure.
Water Temperature
Entering Condenser °C
Freeze Cycle Harvest Cycle
Discharge Pressure Suction Pressure Discharge Pressure Suction Pressure
Set water regulating valve to 15.9 bar 5 minutes into freeze cycle. All pressures are in bar. Suction
pressure drops gradually throughout the freeze cycle.
10 15.86-15.51 3.79-1.79 8.27-9.65 5.52-6.21
20 15.86-15.51 4.48-1.79 8.96-11.38 6.21-8.27
25 15.86-15.51 4.48-1.79 8.96-11.38 6.21-8.27
32 15.86-15.51 4.48-1.79 8.96-11.38 6.55-8.62
43 17.24-16.20 4.83-1.93 9.65-12.07 7.24-9.65
To Next Page
