Item Description
1 Swing Drive
2Fuel Tank
3 Hydraulic Tank
4 Battery Box
5 Diesel Exhaust Fluid (DEF) Tank
6 Engine Air Cleaner
7 Pump Drive with Pumps
8Engine
9 High Pressure Accessory Valve
10 Engine Exhaust System
11 Radiator/Cooler Assembly
Item Description
12 Counterweight Pins (crane)
13 Drum 4 (boom hoist) (drive)
14 A/C Condenser
15 Hydraulic Oil Cooler
16 Drum 3 (optional aux hoist) (drive)
17 Main Control valve
18 Drum 2 (main hoist) (drive)
19 Low Pressure Accessory Valve
20 Crawler Extend and Retract Cylinder
21 Drum 1 (whip hoist) (drive)
22 Crawler Drive
FIGURE 1-2
