Manitowoc Published 10-09-2020, Control # 259-06 3-19
MLC80A-1/MLC90A-1/MLC100A-1/MLC100-1 SERVICE/MAINTENANCE MANUAL ELECTRICAL SYSTEM
3
TEST VOLTAGES
Table 3-7. CCM-10 Test Voltages
Pin Net Function Voltages
P1-1 OPH3A23 Left Travel Side A
0 to 24 V
DC
P1-2 OPH3A28 Drum 4 Side B
0 to 24 V
DC
P1-3 ID21 Drum 4 Pawl Limit Switch N.C.
0 V
DC
Open, 24 V
DC
Closed
P1-4 IDF09 Drum 2 Motor Speed Sensor
6% (low) to 70% (high) of 8.5 V
DC
P1-5 IDF10 Drum 2 Motor Speed Sensor
6% (low) to 70% (high) of 8.5 V
DC
P1-7 IDF01 Drum 4 Motor Speed Sensor
6% (low) to 70% (high) of 8.5 V
DC
P1-8 IDF04 Drum 3 Motor Speed Sensor
6% (low) to 70% (high) of 8.5 V
DC
P1-9 IDF06 Drum 1 Flange Encoder
0 V
DC
or 24 V
DC
P1-11 IACV16 Right Travel Motor PSI 4 to 20 mA
P1-12 IACV18 Drum 2 Motor PSI 4 to 20 mA
P1-13 IACV14 Drum 3 Motor PSI 4 to 20 mA
P1-14 8C48 (+UE) Control Module Battery Power
24 V
DC
P1-15 OPH3A25 Right Side Travel Side A
0 to 24 V
DC
P1-21 IDF03 Drum 3 Motor Speed Sensor
6% (low) to 70% (high) of 8.5 V
DC
P1-22 IDF05 Drum 1 Flange Encoder
0 V
DC
or 24 V
DC
P1-24 IACV14 Drum 4 Motor PSI 4 to 20 mA
P1-25 IACV11 Left Side Travel Motor PSI
4 to 20 mA
P1-27 KL15 Control Module Ignition Power (from engine RUN switch)
0 V
DC
Open, 24 V
DC
Closed
P1-28 OPH3A27 Drum 4 Side A
0 to 24 V
DC
P1-29 GND Ground (from ground stud on rotating bed)
0 V
DC
P1-35 IDF02 Drum 4 Motor Speed Sensor
6% (low) to 70% (high) of 8.5 V
DC
P1-36 IDF07 Drum 2 Flange Encoder
6% (low) to 70% (high) of 8.5 V
DC
P1-37 IDF08 Drum 2 Flange Encoder
6% (low) to 70% (high) of 8.5 V
DC
P1-38 IACV15 Drum 4 Motor PSI 4 to 20 mA
P1-39 IACV13 Drum 2 Motor PSI 4 to 20 mA
P1-40 IACV12 Drum 1 Motor PSI 4 to 20 mA
P1-42 OPH3A26 Right Side Travel Side B
0 to 24 V
DC
P2-2 ODH3A03 Swing Brake Release
0 V
DC
Off, 24 V
DC
On
P2-3 ODH3A03 Drum 4 Pawl In
0 V
DC
Off, 24 V
DC
On
P2-4 ODH3A03 Drum 4 Brake Release
0 V
DC
Off, 24 V
DC
On
P2-5 ODH3A03 Drum 1 Brake Release
0 V
DC
Off, 24 V
DC
On
P2-6 ODH3A03 Counterweight Pin Pull
0 V
DC
Off, 24 V
DC
On
P2-10 GND Ground (from ground stud on rotating bed)
0 V
DC
P2-11 8C31 (+UB) Battery Power for Control Module Outputs
24 V
DC
P2-12 ODH3A10 Left Travel Side B
0 to 24 V
DC
P2-13 ODH3A01 Drum 4 Motor Speed Sensor and Pressure
24 V
DC
P2-14 ODH3A07 Drum 3 Brake Release
0 to 24 V
DC
P2-15 ODH3A06 Drum 2 Brake Release
0 to 24 V
DC
FOR REFERENCE
ONLY
