HYDRAULIC SYSTEM MLC80A-1/MLC90A-1/MLC100A-1/MLC100-1 SERVICE/MAINTENANCE MANUAL
2-6
Published 10-09-2020, Control # 259-06
Drum 4 Motor
Drum 4 motor (Figure 2-8) is an 80 cc bidirectional, fixed-
displacement motor.
Item Description
1 Pressure Port A
2 Pressure Port B
3 Tank Port
4 Pilot Pressure Port S
FIGURE 2-8
