INSTALLATION 800D
9-18
Published 5-27-2018 Control # 039-06
4. If reinforcing is to be welded on, torch cut hole pattern in
reinforcing being careful to clear crane mounting
anchors. Install reinforcing, clamp in place, install any
crossmember bolts that were previously removed and
weld to truck frame as shown in Figure B.
In some cases, because of customer stipulation or truck
manufacturer voiding their warranty, bolt- on reinforcing
is required. In these cases, install the reinforcing, clamp
in place, install any crossmember bolts that were
previously removed, then drill through reinforcing and
truck frame being careful to clear crane mounting
anchors and bolt reinforcing in place. See Figure C for
recommended drilling and bolting procedure. Use 5/8,
Grade 8 bolts, drill holes to 39/64 diameter, drive fit bolts
and torque according to Torque Chart in Maintenance
Section.
Fo
r
Reference
Only
