800D INSTALLATION
1 in (25 mm) DIAMETER HOLES FOR PLUG WELDS
51 mm
2 in
CLEARANCE HOLES FOR
RIVETS – ON WELD – ON
REINFORCEMENT CAN
BE FILET WELDED
AROUDED TO ELIMINATE
PLUG WELD HOLES
CROSSMETER BOLT
HOLES PLUG WELD
HOLES CAN BE SHIFTED
SLIGHTLY TO CLEAR
5 in
(127 mm)
2 in
(51 mm)
4 in
(102 mm)
4 in
(102 mm)
8 in
(203 mm)
PLANNED LOCATION OF MOUNTING
PLATE. PLUG WELD LOCATIONS CAN
BE SHIFTED TO CLEAR PLATE
FIGURE B
51 mm
2 in MIN
203 mm
8 in TYP
4 in
(102 mm)
2 in MIN
(51 mm)
8 in TYP
(203 mm)
FIGURE C
9444
Fo
r
Reference
Only
