4 Test Speed Display
18 Programming Instructions E-Tacho 1323.02
4 Test Speed Display
After having finished the programming, you test the
proper speed display of the E-Tacho by means of the
menu item “Variable speed“.
By means of the testing devices MTC 1602.04 or
ATC 1601.26, you may directly pull down the menu
item. When using the testing device STC 1601.25, the
E-Tacho has to be connected beforehand, as shown in
Fig. 5.
Fig. 5: Wiring diagram “Test speed display“ E-Tacho by means of STC
(1) E-Tacho 1323.02 (3) Line v/n (accessories STC)
(2) STC 1601.25 (4) Power supply line (accessories
STC)
1
2
4
3
