29
D00619EN - v0 SWING OPERATOR - INSTALLATION MANUAL
ID DESCRIPTION SETTINGS DEFAULT
05
Return closing speed with spring
(VECTORM)
RANGE: 1 ÷ 9
(1 = minimum speed, 9 = maximum speed)
5
Wind protection function with the
door closed (VECTORM)
RANGE: 0 ÷ 9
(0 = wind protection deactivated, 9 = maximum wind protection)
0
06 Crushing protection
RANGE: 1 ÷ 9 both opening and closing
(1 = most sensitive ; 9 = least sensitive)
5
07 Accelerations
RANGE: 5 ÷ 30
(Regulating steps of 1) Modifies both accelerations and
decelerations
30
08 Approach angle
RANGE: 10 ÷ 40
[modifies both values (close equal to half (1/2) of the opening)]
20
09 Electronic lock control voltage
0 = 12 VDC
1 = 24 VDC
0
10 Electronic lock types
0 = Not used
For electronic lock types that may be used, see section
‘Management of Electronic Locks’
0
11
Electronic lock impulse duration
or opening delay
RANGE: 0 ÷ 9
The time depends on the type of electronic lock:
see section ‘Management of Electronic Locks’
2
12 Electronic lock closing force RANGE: 0 (min.) ÷ 9 (max.) 5
13 Individual/double mode
0 = Individual
1 = Double Master
2 = Double Slave
0
14
Activation of the electronic lock
according to the selected logic
settings
0 = Deactivated
1 = One Radar
2 = Two Radars
3 = One Radar and Two Radars
3
15
Configuration of the auxiliary
input AUX-IN 1
0 = Disabled persons opening
1 = Emergency opening
2 = Door interlocking with priority
3 = Door interlocking without priority
4 = Lock release feedback
5 = Lock release control
6 = Individual control with operational mode with Double
7 = Puts the door in stand-by (if it is active)
8 = Resets door stand-by
9 = Step-step (1 impulse opens, 1 impulse closes)
10 = Fire alarm
11 = Manual operation
12 = Door closed
0
16
Configuration of the auxiliary
Input AUX-IN 2
0 = Disabled persons opening
1 = Emergency opening
2 = Door interlocking with priority
3 = Door interlocking without priority
4 = Lock release feedback
5 = Lock release control
6 = Individual control with operational mode with Double
7 = Puts the door in stand-by (if it is active)
8 = Resets door stand-by
9 = Step-step (1 impulse opens, 1 impulse closes)
10 = Fire alarm
11 = Manual operation
12 = Door closed
1
17
Configuration of the
auxiliary output AUX-OUT 1
0 = Monitoring the sensors
1 = Interlocking
2 = Open-door state
3 = Closed-door state
4 = Malfunction
5 = Lock control repetition
0
18
Configuration of the
auxiliary output AUX-OUT 2
0 = Monitoring the sensors
1 = Interlocking
2 = Open-door state
3 = Closed-door state
4 = Malfunction
5 = Lock control repetition
1
