Marantz PM-11S3 Service Manual

65
Ref No. Part No. Part Name Remark Q'ty New
OTHERS PARTS
GROUP
H1201 nsp FUSE CLIP(TAPE)
K3001 00D2048549000 2P PIN JACK(18MM)
K3002 00D2048549000 2P PIN JACK(18MM)
K3003 00D2048549000 2P PIN JACK(18MM)
K3004 00D2048549000 2P PIN JACK(18MM)
K3005 00D2048549000 2P PIN JACK(18MM)
K4001 00D2048549000 2P PIN JACK(18MM)
K4501 644010088209S NC3FAH2
K4502 644010088209S NC3FAH2
K5101 00D2048549000 2P PIN JACK(18MM)
K5102 00D2048549000 2P PIN JACK(18MM)
K5103 00D2048549000 2P PIN JACK(18MM)
K5104 00D2048549000 2P PIN JACK(18MM)
K9901 64301014500AS JY-6317#K3-030G N1G, K1G, FN *
K9901 64301014600AS JY-6317x03-030 N1B, U1B *
L2001 00MFC90050130 BL02RN2-R62T2 FERRITE BEAD
L4001 00MLC13240010 320 MH CHOKE COIL (TOROIDAL) N, K
L4002 00MLC13240010 320 MH CHOKE COIL (TOROIDAL) N, K
N1201 nsp B3B-PH-K-S (LF)(SN)
N1751 nsp S3B-PH-K-S (LF)(SN)
N3001 nsp
B6B-EH-TS (LF)(SN) 6P RADIAL TAPING
JST
N3002 nsp B5B-EH-TS (LF)(SN) 5P RADIAL TAPING
N3003 nsp B3B-EH-TS (LF)(SN) 3P RADIAL TAPING
N3004 nsp 15P SOCKET(C125Z2)
N3005 nsp B16B-PH-K-S (LF)(SN)
N3007 nsp S4B-EH
N3008 nsp S3B-EH
N3601 nsp S7B-EH
N3801 nsp
B6B-EH-TS (LF)(SN) 6P RADIAL TAPING
JST
N3802 nsp
B6B-EH-TS (LF)(SN) 6P RADIAL TAPING
JST
N4001 nsp B3B-EH-TS (LF)(SN) 3P RADIAL TAPING
N4002 nsp
B6B-EH-TS (LF)(SN) 6P RADIAL TAPING
JST
N4003 nsp B3B-EH-TS (LF)(SN) 3P RADIAL TAPING
N4501 nsp
B6B-EH-TS (LF)(SN) 6P RADIAL TAPING
JST
N4502 nsp BASE POST 6P S6B-EH NICHIATSU
N4503 nsp B5B-EH-TS (LF)(SN) 5P RADIAL TAPING
N5101 nsp B7B-EH
N5501 nsp 13P SOCKET(C125Z2)
N5502 nsp 13P SOCKET(C125Z2)
N8901 nsp 2P PLUG B2P3S-VH
N9901 nsp S3B-EH
S1201 0630100020040 SRRSIC
S2001 00D2140208003 RELAY(NA24W-K)
S2002 00D2140208003 RELAY(NA24W-K)
S3501 00D2140208003 RELAY(NA24W-K)
S3502 00D2140208003 RELAY(NA24W-K)
S3503 00D2140208003 RELAY(NA24W-K)

Marantz PM-11S3 Specifications

General

Damping factor	100
Amplifier class	-
Frequency range	5 - 100000 Hz
Input sensitivity	240 mV
Audio output channels	2.0 channels
Peak power per channel	200 W
Signal-to-Noise Ratio (SNR)	96 dB
Total Harmonic Distortion (THD)	0.01 %
Dynamic power per channel (8 Ohm)	100 W
XLR in	Yes
Headphone outputs	1
Line inputs (RCA)	2
Headphone connectivity	6.3 mm
Speakers connectivity type	Clamp terminals
Material	Metal
Cooling type	Passive
Product color	Black, Gold
Volume control	Rotary
Connectivity technology	Wired
Power consumption (standby)	0.3 W
Power consumption (typical)	300 W

Weight and Dimensions

Depth	449 mm
Width	440 mm
Height	168 mm
Weight	27000 g
