Marantz PM-11S3 Service Manual

69
Ref No. Part No. Part Name Remark Q'ty New
Q6015 00D2710314903 KTA1024-Y-AT/P
Q6016 00D2710314903 KTA1024-Y-AT/P
Q6017 00D2730471907 KTC3206-Y-AT/P
Q6018 00D2730471907 KTC3206-Y-AT/P
Q6019 21305001420AS KTC3423-Y-U/PH *
Q6020 00D2730471907 KTC3206-Y-AT/P
Q6021 00D2710314903 KTA1024-Y-AT/P
Q6022 21105001420AS KTA1360-Y-U/PH *
Q6027 00D2710314903 KTA1024-Y-AT/P
Q6030 00D2730471907 KTC3206-Y-AT/P
z
Q6031 00D2730445001 2SC4495
z
Q6032 21305001420AS KTC3423-Y-U/PH *
z
Q6033 21105001420AS KTA1360-Y-U/PH *
z
Q6034 00MHK185919C0 2SA1859/C4883 O/O OR Y/Y PAIR
z
Q6035 00MHK185919C0 2SA1859/C4883 O/O OR Y/Y PAIR
z
Q6036 00MHK121619F0 A1216/C2922 O.Y PAIR FORMING
z
Q6037 00MHK121619F0 A1216/C2922 O.Y PAIR FORMING
Q6038 00D2730479909 2N5551S-RTK/P
Q6039 00D2710318909 2N5401S-RTK/P
Q7001 00D2710314903 KTA1024-Y-AT/P
Q7004 00D2730471907 KTC3206-Y-AT/P
Q7009 00D2710314903 KTA1024-Y-AT/P
Q7010 00D2730471907 KTC3206-Y-AT/P
Q7011 00D2710314903 KTA1024-Y-AT/P
Q7012 21105001420AS KTA1360-Y-U/PH *
Q7013 21305001420AS KTC3423-Y-U/PH *
Q7014 00D2730471907 KTC3206-Y-AT/P
Q7015 00D2710314903 KTA1024-Y-AT/P
Q7016 00D2710314903 KTA1024-Y-AT/P
Q7017 00D2730471907 KTC3206-Y-AT/P
Q7018 00D2730471907 KTC3206-Y-AT/P
Q7019 21305001420AS KTC3423-Y-U/PH *
Q7020 00D2730471907 KTC3206-Y-AT/P
Q7021 00D2710314903 KTA1024-Y-AT/P
Q7022 21105001420AS KTA1360-Y-U/PH *
Q7027 00D2710314903 KTA1024-Y-AT/P
Q7030 00D2730471907 KTC3206-Y-AT/P
z
Q7031 00D2730445001 2SC4495
z
Q7032 21305001420AS KTC3423-Y-U/PH *
z
Q7033 21105001420AS KTA1360-Y-U/PH *
z
Q7034 00MHK185919C0 2SA1859/C4883 O/O OR Y/Y PAIR
z
Q7035 00MHK185919C0 2SA1859/C4883 O/O OR Y/Y PAIR
z
Q7036 00MHK121619F0 A1216/C2922 O.Y PAIR FORMING
z
Q7037 00MHK121619F0 A1216/C2922 O.Y PAIR FORMING
Q7038 00D2730479909 2N5551S-RTK/P
Q7039 00D2710318909 2N5401S-RTK/P
Q8001 00D2730464901 KTC3875S-GR-RTK/P
Q8002 00D2730464901 KTC3875S-GR-RTK/P
Q8003 00D2730464901 KTC3875S-GR-RTK/P
Q8004 00D2730464901 KTC3875S-GR-RTK/P
Q8005 00MHT348832A0 TRANSISTOR 2SC4883 O OR Y
Q8006 00D2710312905 KTA1504S-GR-RTK/P
Q8007 21305001240AS KTC3198-GR-AT/P

Marantz PM-11S3 Specifications

General

Damping factor	100
Amplifier class	-
Frequency range	5 - 100000 Hz
Input sensitivity	240 mV
Audio output channels	2.0 channels
Peak power per channel	200 W
Signal-to-Noise Ratio (SNR)	96 dB
Total Harmonic Distortion (THD)	0.01 %
Dynamic power per channel (8 Ohm)	100 W
XLR in	Yes
Headphone outputs	1
Line inputs (RCA)	2
Headphone connectivity	6.3 mm
Speakers connectivity type	Clamp terminals
Material	Metal
Cooling type	Passive
Product color	Black, Gold
Volume control	Rotary
Connectivity technology	Wired
Power consumption (standby)	0.3 W
Power consumption (typical)	300 W

Weight and Dimensions

Depth	449 mm
Width	440 mm
Height	168 mm
Weight	27000 g
