24
(4) Disconnect the connector board.
(5) Remove the screws then disconnect the connector.
(6) Disconnect the connector board.
Board to board
PCB VIDEO ASSY
Connector
PCB VIDEO
PCB PREOUT
PCB FRONT CNTPCB SIDE CNT
Board to board
Board to board
