(3) PCB HDMI is detached from the chassis, and it puts it into the state turned inside out.
Please pave an insulation sheet that is larger than PCB HDMI under PCB.
b
Connect the ground point of PCB to the chassis with a ground lead or the like.
(4) Connect the four extension jig cables.
PCB HDMI
PCB INPUT PCB VIDEO
Insulation sheet
Ground lead
Ground lead
34567
PCB HDMI
Insulation sheet
Insulation sheet
PCB FRONT CNT
PCB HDMI
PCB SIDE CNT
1
2
9
10
8
PCB HDMI
PCB VIDEO
Insulation sheet
PCB FRONT CNT
