Marantz SR5008/U1B - Hdmi Unit (9;14)

AMP
9
AMP PCB ASS'Y
※Parts indicated by "nsp" on this table cannot be supplied.
※The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver gold model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D401-442 00D2760401905 1SS133-DO34-AXIAL LRC K000013300040S 42
D457,458 963201500170D LBAS16HT1G FAST SWITCHING SOD-323 K005041480230S 2
Q401,402 00D2710314903 KTA1024Y,1W/TO92L-REEL J5001024Y0050S 2
Q403 00D2710318909 2N5401S 0.35W/SOT-23 REEL J520254010010S 1
Q405 00D2710318909 2N5401S 0.35W/SOT-23 REEL J520254010010S 1
Q406 00D2730479909 2N5551S 0.35W/SOT-23 REEL J522255510010S 1
Q407,408 00D9600196205 KSA992F,0.5W/TO92-REEL J5000992F0050S 2
Q411,412 00D2730471907 KTC3206Y,1W/TO92L-REEL J5023206Y0050S 2
Q413,414 00D2710314903 KTA1024Y,1W/TO92L-REEL J5001024Y0050S 2
Q415 00D2710318909 2N5401S 0.35W/SOT-23 REEL J520254010010S 1
Q418 00D2730479909 2N5551S 0.35W/SOT-23 REEL J522255510010S 1
Q419,420 00D9600196205 KSA992F,0.5W/TO92-REEL J5000992F0050S 2
Q423,424 00D2730471907 KTC3206Y,1W/TO92L-REEL J5023206Y0050S 2
Q425,426 00D2710314903 KTA1024Y,1W/TO92L-REEL J5001024Y0050S 2
Q427 00D2710318909 2N5401S 0.35W/SOT-23 REEL J520254010010S 1
Q430 00D2730479909 2N5551S 0.35W/SOT-23 REEL J522255510010S 1
Q431,432 00D9600196205 KSA992F,0.5W/TO92-REEL J5000992F0050S 2
Q435,436 00D2730471907 KTC3206Y,1W/TO92L-REEL J5023206Y0050S 2
Q437,438 00D2710314903 KTA1024Y,1W/TO92L-REEL J5001024Y0050S 2
Q439 00D2710318909 2N5401S 0.35W/SOT-23 REEL J520254010010S 1
Q442 00D2730479909 2N5551S 0.35W/SOT-23 REEL J522255510010S 1
Q443,444 00D9600196205 KSA992F,0.5W/TO92-REEL J5000992F0050S 2
Q447,448 00D2730471907 KTC3206Y,1W/TO92L-REEL J5023206Y0050S 2
Q449,450 00D2710314903 KTA1024Y,1W/TO92L-REEL J5001024Y0050S 2
Q451 00D2710318909 2N5401S 0.35W/SOT-23 REEL
J520254010010S 1
Q454 00D2730479909 2N5551S 0.35W/SOT-23 REEL J522255510010S 1
Q455,456 00D9600196205 KSA992F,0.5W/TO92-REEL J5000992F0050S 2
Q459,460 00D2730471907 KTC3206Y,1W/TO92L-REEL J5023206Y0050S 2
Q461,462 00D2710314903 KTA1024Y,1W/TO92L-REEL J5001024Y0050S 2
Q463 00D2710318909 2N5401S 0.35W/SOT-23 REEL J520254010010S 1
Q466 00D2730479909 2N5551S 0.35W/SOT-23 REEL J522255510010S 1
Q467,468 00D9600196205 KSA992F,0.5W/TO92-REEL J5000992F0050S 2
Q471,472 00D2730471907 KTC3206Y,1W/TO92L-REEL J5023206Y0050S 2
Q473,474 00D2710314903 KTA1024Y,1W/TO92L-REEL J5001024Y0050S 2
Q475 00D2710318909 2N5401S 0.35W/SOT-23 REEL J520254010010S 1
Q478 00D2730479909 2N5551S 0.35W/SOT-23 REEL J522255510010S 1
Q479,480 00D9600196205 KSA992F,0.5W/TO92-REEL J5000992F0050S 2
Q483,484 00D2730471907 KTC3206Y,1W/TO92L-REEL J5023206Y0050S 2
ZD401 963202500300D ZJ5.1A-0.5W/5MA-52MM SEMTECH K06005R134522S 1
ZD402,403 963202500410S ZJ4.7B-0.5W/5MA-52MM SEMTECH K06004R744522S 2
ZD404 963202500300D ZJ5.1A-0.5W/5MA-52MM SEMTECH K06005R134522S 1
ZD405,406 963202500410S ZJ4.7B-0.5W/5MA-52MM SEMTECH K06004R744522S 2
ZD407 963202500300D ZJ5.1A-0.5W/5MA-52MM SEMTECH K06005R134522S 1
ZD408,409 963202500410S ZJ4.7B-0.5W/5MA-52MM SEMTECH K06004R744522S 2
ZD410 963202500300D ZJ5.1A-0.5W/5MA-52MM SEMTECH K06005R134522S 1
ZD411,412 963202500410S ZJ4.7B-0.5W/5MA-52MM SEMTECH K06004R744522S 2
ZD413 963202500300D ZJ5.1A-0.5W/5MA-52MM SEMTECH K06005R134522S 1
ZD414,415 963202500410S ZJ4.7B-0.5W/5MA-52MM SEMTECH K06004R744522S 2
ZD416 963202500300D ZJ5.1A-0.5W/5MA-52MM SEMTECH K06005R134522S 1
ZD417,418 963202500410S ZJ4.7B-0.5W/5MA-52MM SEMTECH K06004R744522S 2
ZD419 963202500300D ZJ5.1A-0.5W/5MA-52MM SEMTECH K06005R134522S 1
ZD420,421 963202500410S
ZJ4.7B-0.5W/5MA-52MM SEMTECH K06004R744522S 2
RESISTOR GROUP
R401 nsp 1.2K-J,1/5W-52RE-AX C00001226P520S 1
R402 nsp 100K-J,1/5W-52RE-AX C00001046P520S 1
R403 nsp 270-J,1W-R.RELL C060027165060S 1
R405 nsp 270-J,1W-R.RELL C060027165060S 1
R406 963252100150S DHPTHF1608 471P 115T SMD PTC THERMISTOR F320471001150S 1
R407 nsp 10K-J,1/16W-1608REEL C20001036M160S 1
R409 nsp 150K-J,1/5W-52RE-AX C00001546P520S 1
R410 nsp JUMPER (0.6/52MM) L045084006040S 1
R411 nsp 680K-J,1/5W-52RE-AX C00006846P520S 1
R412 nsp 15K-J,1/5W-52RE-AX C00001536P520S 1
R413,414 nsp 10K-J,1/5W-52RE-AX C00001036P520S 2
R415 963125012630S 22-J,1W-5REEL C060022065050S 1
R416 nsp 22K-J,1/5W-52RE-AX C00002236P520S 1
R417 nsp 180K-J,1/16W-1608REEL C20001846M160S 1
R418 963125010690S 15K-J,2W-R.REEL C060015366050S 1
R419 nsp 22K-J,1/5W-52RE-AX C00002236P520S 1
R420 nsp 220K-J,1/5W-52RE-AX C00002246P520S 1
R421 nsp 22K-J,1/5W-52RE-AX C00002236P520S 1
R422 nsp 470-J,1/5W-52RE-AX C00004716P520S 1
R423 nsp 10K-J,1/16W-1608REEL C20001036M160S 1
R424,425 00D9630345903 RSD-R1-2WJ-0.47 3.5*8.6 P=5MM SMALL R.REEL N113136647820S 2
R426 nsp 5.6K-J,1/16W-1608REEL C20005626M160S 1
R427 nsp 1.2K-J,1/5W-52RE-AX C00001226P520S 1
R428 nsp JUMPER (0.6/52MM) L045084006040S 1
R429 nsp 33K-J,1/5W-52RE-AX C00003336P520S 1
R430,431 00D9630345903 RSD-R1-2WJ-0.47 3.5*8.6 P=5MM SMALL R.REEL N113136647820S 2
R432 nsp 2.7K-J,1/5W-52RE-AX C00002726P520S 1
R433 nsp 220K-J,1/5W-52RE-AX C00002246P520S 1
R434 nsp 3.3K-J,1W-R.REEL C060033265050S 1
R435 nsp 560-J,1/5W-52RE-AX C00005616P520S 1
R436 nsp 470K-J,1/5W-52RE-AX C00004746P520S 1
R437 nsp 33K-J,1/5W-52RE-AX C00003336P520S 1
R438 nsp 220-J,1/5W-52RE-AX C00002216P520S 1
R439 963125012630S 22-J,1W-5REEL C060022065050S 1
R440 nsp 470-J,1/5W-52RE-AX C00004716P520S 1
R441,442 nsp 1K-J,1W-R.REEL C060010265050S 2
R443 nsp 270-J,1W-R.RELL C060027165060S 1
R444 nsp 1.2K-J,1/5W-52RE-AX C00001226P520S 1
R446 nsp 100K-J,1/5W-52RE-AX C00001046P520S 1
