Marantz SR5008/U1B - Exploded View

HDMI
15
REF No. Part No. Part Name Remarks Q'ty New Ver
R1260,1261 nsp 2.2K-J,1/16W-1005REEL C20002226M101S 2
R1262,1263 nsp 0-J,1/16W-1005REEL C20000006M101S 2
R1267 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1303 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1306-1309 nsp 24-J,1/16W-1608REEL C20002406M160S 4
R1311,1312 nsp 0-J,1/16W-1005REEL C20000006M101S 2
R1313 nsp 2.2K-J,1/16W-1005REEL C20002226M101S 1
R1314,1315 nsp 51-J,1/16W-1608REEL C20005106M160S 2
R1317 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1318 nsp 3.3K-J,1/16W-1005REEL C20003326M101S 1
R1319,1320 nsp 51-J,1/16W-1608REEL C20005106M160S 2
R1323 nsp 680-J,1/16W-1005REEL C20006816M101S 1
R1325 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1329 nsp 47K-J,1/16W-1005REEL C20004736M101S 1
R1331 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R1333 nsp 680-J,1/16W-1005REEL C20006816M101S 1
R1334,1335 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 2
R1336,1337 nsp 2.2K-J,1/16W-1005REEL C20002226M101S 2
R1338 nsp 1K-J,1/16W-1005REEL C20001026M101S 1
R1339,1340 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 2
R1342-1344 nsp 47K-J,1/16W-1005REEL C20004736M101S 3
R1345 nsp 2.2K-J,1/16W-1005REEL C20002226M101S 1
R1346 nsp 0-J,1/16W-1608REEL C20000006M160S 1
R1350 nsp 0-J,1/10W-2012REEL C200000060200S 1
R1352 nsp 470-D,1/16W-1608REEL C20004711M160S 1
R1360 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R1361 nsp 47K-J,1/16W-1005REEL C20004736M101S 1
R1363 nsp 680-J,1/16W-1005REEL C20006816M101S
1
R1368 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1369,1370 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 2
R1401,1402 nsp 10-J 1/16W SMD(1005)*4 WA04X C180100042100S 2
R1403,1404 nsp 47-J 1/16W SMD(1005)*4 WA04X C180470042100S 2
R1407-1409 nsp 4.7K-J 1/16W SMD(1005)*4 WA04X C180472042100S 3
R1410-1412 nsp 47K-J 1/16W SMD(1005)*4 WA04X C180473042100S 3
R1413-1417 nsp 4.7K-J 1/16W SMD(1005)*4 WA04X C180472042100S 5
R1419 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1617,1618 nsp 1K-D,1/16W-1608REEL C20001021M160S 2
R1619,1620 nsp 470-D,1/16W-1608REEL C20004711M160S 2
R1622 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R1623 nsp 1.3K-J,1/16W-1608REEL C20001326M160S 1
R1624 nsp 2.2K-J,1/16W-1608REEL C20002226M160S 1
R1628 nsp 2.7K-F,1/16W-1608REEL C20002724M161S 1
R1629 nsp 180-F,1/16W-1608REEL C20001814M161S 1
R1630 nsp 2.7K-F,1/16W-1608REEL C20002724M161S 1
R1631 nsp 180-F,1/16W-1608REEL C20001814M161S 1
R1632 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R1636 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1637,1638 nsp 10K-J,1/16W-1608REEL C20001036M160S 2
R1639 nsp 1K-J,1/16W-1005REEL C20001026M101S 1
R1640 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R1641 nsp 1.8K-J,1/16W-1005REEL C20001826M101S 1
R1645,1646 nsp 33-J,1/16W-1005REEL C20003306M101S 2
R1647 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1648 nsp 1.8K-J,1/16W-1005REEL C20001826M101S 1
R1649-1652 nsp 0-J,1/16W-1005REEL
C20000006M101S 4
R1653 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1654 nsp 5.1-J,1/16W-1005REEL C2005R106M101S 1
R1657 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1658 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R1659 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1660 nsp 10-J 1/16W SMD(1005)*4 WA04X C180100042100S 1
R1661 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1662 nsp 56-J,1/16W-1005REEL C20005606M101S 1
R1663-1665 nsp 47-J,1/16W-1005REEL C20004706M101S 3
R1667-1670 nsp 47-J,1/16W-1005REEL C20004706M101S 4
R1673 nsp 47-J 1/16W SMD(1005)*4 WA04X C180470042100S 1
R1675-1679 nsp 47-J 1/16W SMD(1005)*4 WA04X C180470042100S 5
R1680 nsp 33-J 1/16W SMD(1005)*4 WA04X C180330042100S 1
R1681-1689 nsp 47-J 1/16W SMD(1005)*4 WA04X C180470042100S 9
R1690 nsp 33-J 1/16W SMD(1005)*4 WA04X C180330042100S 1
R1691-1694 nsp 4.7K-J 1/16W SMD(1005)*4 WA04X C180472042100S 4
R1695 nsp 56-J,1/16W-1005REEL C20005606M101S 1
R1696-1698 nsp 33-J 1/16W SMD(1005)*4 WA04X C180330042100S 3
R1699,1700 nsp 51-D,1/16W-1608REEL C20005101M160S 2
R1702-1706 nsp 33-J 1/16W SMD(1005)*4 WA04X C180330042100S 5
R1707 nsp 10K-J*4 1/16W SMD(1005) WA04 C180103042100S 1
R1715 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1717-1728 nsp 0-J,1/16W-1005REEL C20000006M101S 12
R1729 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1730-1734 nsp 0-J,1/16W-1005REEL C20000006M101S 5
R1818,1819 nsp 1K-D,1/16W-1608REEL C20001021M160S 2
R1820,1821 nsp
10K-J,1/16W-1005REEL C20001036M111S 2
R2003 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R2004 nsp 1K-J,1/16W-1005REEL C20001026M101S 1
R2006 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R2008 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R2011 nsp 47-J,1/16W-1005REEL C20004706M101S 1
R2012 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R2014,2015 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 2
R2016,2017 nsp 33-J,1/16W-1005REEL C20003306M101S 2
R2018 nsp 10-J,1/16W-1005REEL C20001006M101S 1
R2019 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R2020 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R2021 nsp 1M-J,1/16W-1005REEL C20001056M101S 1
R2022 nsp 47-J,1/16W-1005REEL C20004706M101S 1
R2023 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R2024,2025 nsp 0-J,1/16W-1005REEL C20000006M101S 2
R2026 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R2027 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R2028 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R2030 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R2031 nsp 33-J,1/16W-1005REEL C20003306M101S 1
