Marantz SR5008/U1B - Page 155

HDAM
23
HDAM PCB ASS'Y
※Parts indicated by "nsp" on this table cannot be supplied.
※The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver gold model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D4020-4035 963201500170D LBAS16HT1G FAST SWITCHING SOD-323 K005041480230S 16
IC4000-4007 963232100390S NJM8080G SOP8 DUAL OP AMP J121808000010S 8
Q4050,4051 00D9630148508 KTA1504S-Y 0.15W SOT-23 REEL J520015040150S 2
Q4052-4055 00D2730464901 KTC3875G(ALG) 0.15W/SMT-REEL J5223875G0210S 4
Q4056-4059 00D9630148508 KTA1504S-Y 0.15W SOT-23 REEL J520015040150S 4
Q4060-4063 00D2730464901 KTC3875G(ALG) 0.15W/SMT-REEL J5223875G0210S 4
Q4064-4067 00D9630148508 KTA1504S-Y 0.15W SOT-23 REEL J520015040150S 4
Q4068-4071 00D2730464901 KTC3875G(ALG) 0.15W/SMT-REEL J5223875G0210S 4
Q4072-4075 00D9630148508 KTA1504S-Y 0.15W SOT-23 REEL J520015040150S 4
Q4076-4079 00D2730464901 KTC3875G(ALG) 0.15W/SMT-REEL J5223875G0210S 4
Q4080-4083 00D9630148508 KTA1504S-Y 0.15W SOT-23 REEL J520015040150S 4
Q4084-4087 00D2730464901 KTC3875G(ALG) 0.15W/SMT-REEL J5223875G0210S 4
Q4088-4091 00D9630148508 KTA1504S-Y 0.15W SOT-23 REEL J520015040150S 4
Q4092-4095 00D2730464901 KTC3875G(ALG) 0.15W/SMT-REEL J5223875G0210S 4
Q4096,4097 00D9630148508 KTA1504S-Y 0.15W SOT-23 REEL J520015040150S 2
RESISTOR GROUP
R4153 nsp 470-J,1/16W-1608REEL C20004716M160S 1
R4154 nsp 0-J,1/10W-1608REEL C200000060161S 1
R4155,4156 nsp 470-J,1/16W-1608REEL C20004716M160S 2
R4157 nsp 0-J,1/10W-1608REEL C200000060161S 1
R4158 nsp 470-J,1/16W-1608REEL C20004716M160S 1
R4159,4160 nsp 33K-J,1/16W-1608REEL C20003336M160S 2
R4161,4162 nsp 470-J,1/16W-1608REEL C20004716M160S 2
R4163,4164 nsp 330-J,1/16W-1608REEL C20003316M160S 2
R4165,4166 nsp 5.6K-J,1/16W-1608REEL C20005626M160S 2
R4167,4168 nsp
22-J,1/16W-1608REEL C20002206M160S 2
R4169,4170 nsp 0-J,1/10W-1608REEL C200000060161S 2
R4171,4172 nsp 100-J,1/16W-1608REEL C20001016M160S 2
R4173,4174 nsp 22-J,1/16W-1608REEL C20002206M160S 2
R4175 nsp 330-J,1/16W-1608REEL C20003316M160S 1
R4176 nsp 22-J,1/16W-1608REEL C20002206M160S 1
R4177 nsp 330-J,1/16W-1608REEL C20003316M160S 1
R4178 nsp 22-J,1/16W-1608REEL C20002206M160S 1
R4181,4182 nsp 1M-J,1/16W-1608REEL C20001056M160S 2
R4183,4184 nsp 33K-J,1/16W-1608REEL C20003336M160S 2
R4185,4186 nsp 22-J,1/16W-1608REEL C20002206M160S 2
R4187,4188 nsp 5.6K-J,1/16W-1608REEL C20005626M160S 2
R4189,4190 nsp 330-J,1/16W-1608REEL C20003316M160S 2
R4191-4194 nsp 470-J,1/16W-1608REEL C20004716M160S 4
R4195,4196 nsp 330-J,1/16W-1608REEL C20003316M160S 2
R4197,4198 nsp 5.6K-J,1/16W-1608REEL C20005626M160S 2
R4199,4200 nsp 22-J,1/16W-1608REEL C20002206M160S 2
R4201 nsp 1M-J,1/16W-1608REEL C20001056M160S 1
R4203 nsp 1M-J,1/16W-1608REEL C20001056M160S 1
R4205,4206 nsp 33K-J,1/16W-1608REEL C20003336M160S 2
R4207,4208 nsp 330-J,1/16W-1608REEL C20003316M160S 2
R4209,4210 nsp 100-J,1/16W-1608REEL C20001016M160S 2
R4211,4212 nsp 22-J,1/16W-1608REEL C20002206M160S 2
R4213,4214 nsp 0-J,1/10W-1608REEL C200000060161S 2
R4215-4218 nsp 22-J,1/16W-1608REEL C20002206M160S 4
R4219,4220 nsp 5.6K-J,1/16W-1608REEL C20005626M160S 2
R4221,4222 nsp 330-J,1/16W-1608REEL C20003316M160S 2
R4223,4224
nsp 470-J,1/16W-1608REEL C20004716M160S 2
R4225,4226 nsp 33K-J,1/16W-1608REEL C20003336M160S 2
R4227 nsp 470-J,1/16W-1608REEL C20004716M160S 1
R4228 nsp 0-J,1/10W-1608REEL C200000060161S 1
R4229,4230 nsp 470-J,1/16W-1608REEL C20004716M160S 2
R4231 nsp 0-J,1/10W-1608REEL C200000060161S 1
R4232,4233 nsp 470-J,1/16W-1608REEL C20004716M160S 2
R4234 nsp 0-J,1/10W-1608REEL C200000060161S 1
R4235,4236 nsp 470-J,1/16W-1608REEL C20004716M160S 2
R4237 nsp 0-J,1/10W-1608REEL C200000060161S 1
R4238 nsp 470-J,1/16W-1608REEL C20004716M160S 1
R4239,4240 nsp 33K-J,1/16W-1608REEL C20003336M160S 2
R4241,4242 nsp 470-J,1/16W-1608REEL C20004716M160S 2
R4243,4244 nsp 330-J,1/16W-1608REEL C20003316M160S 2
R4245,4246 nsp 5.6K-J,1/16W-1608REEL C20005626M160S 2
R4247,4248 nsp 22-J,1/16W-1608REEL C20002206M160S 2
R4249,4250 nsp 0-J,1/10W-1608REEL C200000060161S 2
R4251,4252 nsp 100-J,1/16W-1608REEL C20001016M160S 2
R4253,4254 nsp 22-J,1/16W-1608REEL C20002206M160S 2
R4255 nsp 330-J,1/16W-1608REEL C20003316M160S 1
R4256 nsp 22-J,1/16W-1608REEL C20002206M160S 1
R4257 nsp 330-J,1/16W-1608REEL C20003316M160S 1
R4258 nsp 22-J,1/16W-1608REEL C20002206M160S 1
R4261,4262 nsp 1M-J,1/16W-1608REEL C20001056M160S 2
R4263,4264 nsp 33K-J,1/16W-1608REEL C20003336M160S 2
R4265,4266 nsp 22-J,1/16W-1608REEL C20002206M160S 2
R4267,4268 nsp 5.6K-J,1/16W-1608REEL C20005626M160S 2
R4269,4270 nsp 330-J,1/16W-1608REEL C20003316M160S 2
R4271-4274 nsp 470-J,1/16W-1608REEL C20004716M160S 4
R4275,4276 nsp 330-J,1/16W-1608REEL C20003316M160S 2
R4277,4278 nsp 5.6K-J,1/16W-1608REEL C20005626M160S 2
R4279,4280 nsp 22-J,1/16W-1608REEL C20002206M160S 2
R4281 nsp 1M-J,1/16W-1608REEL C20001056M160S 1
R4283 nsp 1M-J,1/16W-1608REEL C20001056M160S 1
R4285,4286 nsp 33K-J,1/16W-1608REEL C20003336M160S 2
R4287,4288 nsp 330-J,1/16W-1608REEL C20003316M160S 2
R4289,4290 nsp 100-J,1/16W-1608REEL C20001016M160S 2
R4291,4292 nsp 22-J,1/16W-1608REEL C20002206M160S 2
R4293,4294 nsp 0-J,1/10W-1608REEL C200000060161S 2
R4295-4298 nsp 22-J,1/16W-1608REEL C20002206M160S 4
